BRS39BWC61ACA Schneider 3-phase Stepper Motor

Schneider BRS39BWC61ACA 3-phase Stepper Motor :

The BRS39BWC61ACA is a 3-phase stepper motor manufactured by Schneider Electric, designed for high-precision motion control applications. It features a shaft diameter of 14 mm, a total length of 171 mm, and a flange size of 85 mm (3.35 inches). This motor operates without an integrated brake and uses a connector for electrical connections. It is compatible with Schneider’s Lexium SD3 drive range, making it suitable for integration into automated systems requiring reliable and precise positioning.

Technical Specifications:

Motor Type: 3-phase stepper motor

Number of Poles: 6

Holding Torque: 6.78 Nm (60.01 lbf·in)

Continuous Stall Torque: 5.78 Nm (51.16 lbf·in)

Rotor Inertia: 3.3 kg·cm²

Maximum Mechanical Speed: 3,000 rpm

Supply Voltage Limits: 230 V AC / 325 V DC

Line Rated Current: 2.25 A

Winding Resistance: 6.5 Ω

Step Angle Resolution: Configurable to 1.8°, 0.9°, 0.72°, 0.36°, 0.18°, 0.09°, 0.072°, or 0.036° per step

Accuracy Error: ±6 arc minutes

Maximum Starting Frequency: 5.3 kHz

Mechanical Dimensions:

Shaft length: 30 mm
ring collar diameter: 60 mm (2.36 inches)

Net weight: 4.3 kg

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
